The LS321G is a class IIIa visible green laser aiming device with a coaxial mounted class 2 IR (infrared) laser and IR illuminator for use with night vision devices. The LS321G features a 7075-aluminum matte black anodized housing with a quick release Picatinny rail mount.
The LS321G is powered by a single CR123 battery which can provide up to 5000 hours of battery life.
The rear facing selector switch lets the user select between visible low, visible high, IR high, IR illuminator, or IR high with IR illuminator activation using the included remote pressure switch or turn the unit OFF.
The LS321G also includes a top mounted activation button and tactile windage and elevation adjustments for a precision zero.
Electronic Specifications:
- Power Source : Battery
- Battery Type: CR123A
Physical Specifications:
- Dimension (in): 3.6×2.2×1.6
- Weight (oz): 8.64
Mechanical Specifications:
- Adjustment per Click: 0.5 MOA
- W&E Travel Range: ±50 MOA
Environment Specificatons:
- Storage Temperature: -40℃~65℃
- Working Temperature: -40℃~51℃
- Submersion: IP67
- Vibration: 1000G
Illminator Specifications:
- White LED Candela N/A
- Laser & Illuminator Type Dual Laser & IR Illuminator
- White LED Output N/A
- IR Illuminator Class: IIIB
- IR Illuminator Output: 0.7mw
- IR Pointer Class: IIIB
- IR Pointer Output: 0.1mw(low)/0.7mw(high)
- Visible Laser Class: IIIA
- Visible Laser Output: 1mw(low)/5mw(high)
